Valor VL100 Pro
- Payments: Accepts EMV chip, magnetic stripe, and contactless payments.
- Screen: Wide 3.5” Color.
- Connectivity: Ethernet, WiFi, and 4-G.
- Security: PCI PTS 6.x certified.
- Keypad: Integrated with backlit keys
- Features: Built in NFC reader and printer, LED indicators Cash discounting, Dual pricing, Surcharging
Overview
The VL100 Pro is an advanced countertop POS terminal that supports EMV chip, magnetic stripe, and contactless payments. It features a 3.5” Color TFT LCD display and offers multiple connectivity options including Ethernet, WiFi, and Dial-Up. The device is PCI PTS 5.x certified for secure transactions.
Specifications
- Operating System: Secure Linux-based OS
- Processor: 32-bit ARM Secure Microprocessor
- Memory: 128MB Flash, 64MB DDR RAM
- Display: 2.8” Color TFT LCD (240 x 320 pixels)
- Magnetic Stripe: ISO 7810, 7811, 7813 Triple track, bi-directional
- Contact Card: EMV Level 1 & 2
- Contactless: ISO 14443 Type A, B
- Camera: None
- Barcode Scanner: Optional 1D/2D barcode scanner
- Connectivity: Wi-Fi, Bluetooth, USB
- Printer: Built-in thermal dot receipt printer
- Paper Size: 2-1/4" x 50' (57mm x 15.2m)
- Additional Features: Audio Buzzer, PCI PTS 5.0, Digital Signature Capture, Paperless Signature / Receipt Option, Bill Splitting, Cash Discounting, Surcharge on Tip
Downloads
Product Specification
VL100 Gen Specs
Quick Reference Guide
VL100 Gen QRG
