Dejavoo P17 Pin Pad
- Android Dejavoo P17 Pin Pad delivers fast, secure payment acceptance with a modern Android operating system.
- 4.0" HD Touchscreen features a bright 480 × 480 IPS display with an intuitive touch interface for customers and staff.
- All-in-One Payment Acceptance supports EMV chip, NFC/contactless, and magnetic stripe transactions.
- Compact Countertop Design is ideal for retail, hospitality, and healthcare environments where space is limited.
- USB & Wi-Fi Connectivity provides flexible deployment for integrated POS environments.
- ADA Compliant design improves accessibility for all customers.
- Enterprise-Grade Security with PCI PTS 6.x certification and industry-standard encryption technologies.
Overview
The Dejavoo P17 Secure Android PIN Pad is a customer-facing payment terminal designed to enhance countertop payment experiences. Running Android 11, the P17 combines a responsive HD touchscreen with support for EMV chip, contactless, and magnetic stripe transactions in a compact, ADA-compliant form factor. Built for retail, hospitality, and healthcare environments, it integrates easily with POS systems through USB and Wi-Fi while delivering enterprise-grade security and dependable payment performance.
Specifications
- Processor & OS: Quad-Core 1.3GHz Cortex A7 processor running Android 11.
- Memory & Display: 1GB RAM + 16GB ROM LPDDR3 (2GB + 16GB optional), 4.0" HD IPS touchscreen (480 × 480 resolution).
- Connectivity: USB Type-C, Wi-Fi, audio jack, three Mini SAM slots.
- Payments & Readers: EMV smart card, NFC/contactless, magnetic stripe reader, PayPass, PayWave, AMEX ExpressPay, Discover D-PAS, JCB support.
- Battery & Cameras: Integrated 3.7V / 800mAh Li-polymer battery, 2MP front camera with optional 0.3MP or 5MP camera configurations.
- Physical Design: 201.83 × 79.24 × 68.37mm, 408g, integrated speaker, compact countertop PIN pad design.
- Security & Certifications: PCI PTS 6.x (SRED), EMVCo L1/L2, EMV Contactless L1, ANSI X9.8, ANSI X9.9, ISO 9564, 3DES, RSA, SHA-256 encryption.
